BP系列工业级不锈钢316潜水泵
特点
1.整体采不锈钢SCS14(SUS316)材质脱腊铸造制成，可抽 取有微酸弱碱之污物废水。
2.电缆线基座及芯线均经特殊断漏防水处理，内单蕊线采剥 离封装处理，有效防止水气从
电缆线缝或芯线渗入电机，充 份达到防漏、防潮湿的密封效果。
3.锥型泵壳及涡流式叶轮，经特殊不阻塞设计，抽取污泥、 污物均可事半功倍。
4.机械轴封部位搭载高品质双组式S1C硅碳钢机械轴封及 VITON氟橡胶之密封件组合，有
效提升不锈钢泵于微酸弱碱 环境上使用，延长泵浦的使用寿命。
5.电机采用绝缘等级F级（155°C)之干式感应电动机，外壳 防护等级为IP68。
6.全系列电机配置温度控制器或电机保护器，有效防止电机 异常过载时的烧毁。
7.全系列可选购搭配自动着脱架装置设备，藉由简便的安装 施工将输水管固定接于着脱架
装置的主体鞍座上，遇泵浦须 保养、修护时可轻易的藉由吊炼顺由导杆进行升降、脱离、
接合等作业，工程人员无须进入水槽拆装，有效提升作业时 之便利性与安全性。
Features
1. The whole stainless steel SCS14 (SUS316) material is made by de-waxing and can be used to extract
waste water with slightly acid and weak alkali.
2. The cable base and the core wire are treated with special water leakage and leakage treatment. The inner
single core wire is used for stripping and encapsulation to effectively prevent water vapor from penetrating
into the motor from the cable seam or core wire, fully meeting the leakproof and moistureproof seal.
effect.
3. Cone pump casing and vortex impeller, with special non-blocking design, sludge and dirt can be
extracted with less effort.
4. Mechanical shaft seals are equipped with high-quality double-set S1C silicon carbon steel mechanical
shaft seals and VITON fluoroelastomer seals to effectively enhance the use of stainless steel pumps in
slightly acidic and weakly alkaline environments to extend pump life.
5. The motor uses a dry induction motor with insulation class F (155°C) and the enclosure protection
class is IP68.
6. The full series of motor configuration temperature controller or motor protector can effectively prevent
the motor from burning when it is abnormally overloaded.
7. The whole series can be used with the equipment for automatic assembly and disassembly device, and
the water pipe can be fixedly connected to the main saddle of the dismounting device through simple
installation and installation. When the pump is required to be maintained and repaired, it can be easily
lifted. The smelter lifts, detaches, and engages with the guide bar. The engineer does not need to go into
the sink for disassembly and assembly, effectively improving the convenience and safety during operation.
|
