BKS系列卧式铜材质多级增压泵
应用范围
家用, 工业供水或园艺灌溉等
安静运作的多级离心泵,内置自吸阀,自吸可达8米不抽带颗粒杂质的液体
水泵
最大流量可达10.2吨每小时最高扬程可达75米
所泵液体温度：0-80摄氏度最大工作压力：10公斤
电机
异步，两极
保护等级 IPX5
绝缘等级 F级
可连续工作
单相220-240V 50Hz 内置过热保护器
三相 220-240V / 380-415V 50Hz
过载保护需要由用户另行购买及安装于控制盒中
工作环境最高温度40摄氏度
材质
进/出口连接体铸铁或铜（可选）详见参考数表
泵体不锈钢304
导叶PPO材质
叶轮不锈钢304
电机轴416材质(可用碳钢或是不锈钢316)
机械密封件：石墨及陶瓷，丁腈橡胶，其余部分为304不锈钢
O型圈为NBR丁腈橡胶（另外有EPDM可选）
可选配置
不同电压及频率Hz可选
密封件可根据需要选用不同材质M系列为220V电压
T系列为380V电压
Applications
For domestic and industrial applications, irrigation ect
Quiet running multistage centrifugal pump. Built-in self priming valve, not very sensitive to the impurities.
Self-priming up to 8 m
Pump
Maximum capacity up to 170 l/min(10.2m 3/h) Head up to 75m.
Temperature of pumped liquid: 0-80℃Maximum Operating Pressure: 10.0 Bar
Motor
Asynchronous, Two Poles
Protection Class: IPX5
Insulation Class: F
Continuous Operation.
Single Phase Version: 220-240V 50Hz with automatic reset overload protection.
Three Phase Version: 220-240V/380-415V 50Hz, the overload protection must be provided and installed
by the user in the control panel.
Maximum ambient temperature 40℃
Material
Suc tion/Disc ha rge Mounting in C a sting Iron (C a sting Bra ss is available)
Pump Housing in SUS 304 Stainless Steel.
Diffuser in PPO.
Impellers in SUS 304 Stainless Steel
Motor Shaft in SUS 416 Stainless Steel (Carbon Steel and SUS 316 Stainless Steel are available).
Mechanical seal with Ceramic/Graphite, NBR elastomers, other parts are made of Stainless Steel 304
O-ring made of NBR (EPDM is available)
Optional Features
Different Voltages and Frequencies. Different Materials for the Mechanical Seal.
M series for the 220V voltage
T series for the 380V voltage
|
